You are smart so should
be your Home & Office


Save time, money and energy all at once

Control from Anywhere In the World



Turn On/Off devices from anywhere

Voice Command your Home and Office



Smoothly works with Amazon Alexa and Google Home

Affordable & Compact



Easy install and configure without Re-Wiring or changes

About SpikeBot

IR Remote Security Camera Fan Lights Water Pump A/C TV Door Window Geyser

Features

Floor Plan Pump Sensor Switches Sensor Spikebot Geyser High Loads High Loads Camera Sensor Remote Sensor Door Sensor

Switches Sensor
Accessible from any location through Wi-Fi and mobile data

Loading ....

Installation and Product Specifications



Gateway
  • SpikeBot Gateway
    • Broadcom BCM2837B0, Cortex-A53 (ARMv8) 64-bit SoC @ 1.4GHz
    • 1GB LPDDR2 SDRAM
    • 2.4GHz and 5GHz IEEE 802.11.b/g/n/ac wireless LAN, Bluetooth 4.2, BLE
    • Gigabit Ethernet over USB 2.0 (maximum throughput 300 Mbps)
    • Micro SD port for loading your operating system and storing data
    • 5V/2.5A DC power input


5F
  • SpikeBot 5F
    • Load 1: Switch on/off, regulate fan speedup to 100W
    • Load 2 – Load 5: 1100W on each load point
    • Operating range: 110 – 270 V AC
    • SMPS output: 500mA at 5V DC
    • Communication: 2.4-GHz ZigBee IEEE 802.15.4Standard
    • Variants & Load Capabilities
    • L: 84 X B: 48 X H: 20 mm (suitable to fit in congested space behind Switch boards)


5F
  • SpikeBot 5
    • Load 1 – Load 5: 1100W on each load point
    • Operating range: 110 – 270 V AC
    • SMPS output: 500mA at 5V DC
    • Communication: 2.4-GHz ZigBee IEEE 802.15.4Standard
    • Variants & Load Capabilities
    • L: 84 X B: 48 X H: 20 mm (suitable to fit in congested space behind Switch boards


HL
  • SpikeBot High Load
    • Load : 3000W on load point (For heavy loads like AC, Geyser etc)
    • Operating range: 110 – 270 V AC
    • SMPS output: 500mA at 5V DC
    • Communication: 2.4-GHz ZigBee IEEE 802.15.4Standard
    • Variants & Load Capabilities
    • L: 60 X B: 48 X H: 20 mm


Temperature
  • SpikeBot Temperature Sensor
    • Temperature sensing range: -40 to 85 ̊C (-40 to 185 ̊F)
    • Temperature accuracy : +/- 0.5 ̊C
    • Temperature update interval: 30 minutes
    • Battery Lifetime: up to 6 months
    • Battery specification: 3V 620maH, CR2450
    • Dimensions - L: 50 X B: 32 X H: 17 mm


Door
  • SpikeBot Door
    • Door/Window Open-Close Sensing
    • Response time <0.5 second
    • Battery Lifetime: up to 6 months
    • Battery specification: 3V 620maH , CR2450
    • Dimensions - L: 50 X B: 32 X H: 17 mm


IRBlaster
  • SpikeBot IR Blaster
    • IR – 38 KHz frequency, omni directional (6 transmitters)
    • Communication: 2.4-GHz ZigBee IEEE 802.15.4Standard
    • Supported Appliances: IR remote AC, TV
    • Power – 5V/1A via USB port
    • Dimensions – 48 x 48 x 43 mm

Smart Zigbee Remote
  • Spikebot Remote
    • Zigbee protocol 2.4 Ghz IEEE802.15.4 Standard
    • Battery Lifetime: up to 12 months
    • Battery specification: 3V 620maH, CR2450
    • Dimensions - L: 75 X B: 50 X H: 20 mm
    • Operating range: -40 to 85 ̊C (-40 to 185 ̊F)
    • Max 3 digit number based ON/OFF operation

Yele Lock
  • SpikeBot Door Lock
    • Operation: Door Lock and Door unlock
    • Operating range: 5V DC/2A via USB Port
    • Communication: 2.4-GHz ZigBee IEEE 802.15.4Standard
    • Dimensions: 96 X B: 33 X H: 40 mm
    • Operating Temp range: -40 c to 85 c(-40 F to 185 F)

Curtains
  • SpikeBot Curtain Module
    • Load1-For open curtain(For horizontal and vertical Blind)
    • Load2-For close curtain(For horizontal and vertical Blind)
    • Operating range: 110 – 270 V AC
    • SMPS output: 500mA at 5V DC
    • Communication: 2.4-GHz ZigBee IEEE 802.15.4Standard
    • Variants & Load Capabilities
    • Dimensions: 84 X B: 54 X H: 25 mm (suitable to fit in congested space behind Switch boards)

Spikebot Camera
  • SpikeBot Camera
    • Link any DVR/NVR/ IP camera system to SpikeBot APP get live stream of cameras
    • No need to use separate app for cameras.
    • You can also record to external HDD.
    • Now Introducing Artificial Intelligence based Human Detection on cameras
    • Which only sends notifications with snapshot
    • If there is human detected on your cameras during off-hours or when you are away.

Wemo And Philips
  • Philips Hue/ TP-Link/ MI
    • You can use Spikebot APP to control your 3rd Party Bulbs.
    • Their features make it part of the room.
    • No need to operate via separate app.
    • Make it smart with Schedule and Moods via SpikeBot APP

Alexa
  • Alexa & Google Home
    • SpikeBot is seamlessly integrated with Alexa and Google Home.
